Introduction

Composite Geomembrane are made of polyester staple fiber geotextile,polypropylene staple fiber and polyester continuous filament geotextile as the base material and high-density polyethylene as the geomembrane material by composite. There are one geotextile and one geomembrane,two geotextiles and one geomembrane,two geomembranes and one geotextile,multi-geotextiles and multi-geomembrane etc.The product max width 6m,length 50m-100m,u can customize it.

Properties Of Composite Geomembrane

 *High tensile strength and good elongation

*Resistant to acid and alkali corrosion

*Good durability

*High mechanical index

*High puncture resistance and high friction coefficient

*Good aging resistance

*Excellent anti-drainage performance

Advantages Of Composite Geomembrane

*It has good plane drainage and excellent anti-seepage characteristics

*It has the characteristics of high tensile trength, good elongation performance, large friction coefficient, large deformation modulus, acid and alkali resistance, corrosion resistance, aging resistance and so on

*It has a certain heat preservation effect and reduces the damage of soil frost heave to geomembrane

*Stable low-temperature embrittlement resistance

*Excellent Chemical and UV Resistance

*Easy to install and save cost

 Application Of Composite Geomembrane

*Landfill, sewage or waste disposal seepage prevention

*River dike, lake dam, tailings dam, sewage dam and reservoir area, channel, reservoir

*Subway, basement and tunnel, tunnel anti-seepage lining

*Subgrade and other foundation salt seepage prevention

*Embankment, horizontal anti-seepage blanket in front of dam, vertical anti-seepage layer of foundation, construction cofferdam, waste yard

Seawater, freshwater farms

*Roads, highways, railway foundations, expansive soil and collapsible loess waterproof layer

*Roof seepage prevention

*Airport runway apron,water conservancy project etc

Specification Of Composite Geomembrane :

Test Item	Test Properties	Unit	400	500	600	700	800	900	1000
Weight		g/m2	400	500	600	700	800	900	1000
Geomembrane Thickness		mm	0.25-0.35			0.30-0.50
Mechanical Properties	Break Strength	kN/m	5.0	7.5	10.0	12.0	14.0	16.0	18.0
	Break Elongation	%	30-100
	CBR Burst Strength	KN	1.1	1.5	1.9	2.2	2.5	2.8	3.0
	Tear Resistance	KN	0.15	0.25	0.32	0.40	0.48	0.56	0.62
	Peel Strength	N/cm	≥6	≥6	≥6	≥6	≥6	≥6	≥6
Hydrostatic Pressure	Geomembrane Thickness	mm	0.2	0.3	0.4	0.5	0.6	0.7	0.8
	One geotextile one geomembrane	MPa	0.4	0.5	0.6	0.8	1.0	1.2	1.4
	Two geotextile one geomembrane	MPa	0.5	0.6	0.8	1.0	1.2	1.4	1.6
